CANopen to KNX
Part No.: MPADFW-CANopen-to-KNX
This series of products allows to integrate a CAN network with a KNX net.
產品介紹
CAN / KNX - Converter
CANopen / KNX - Converter
This series of products allows to integrate a CAN network with a KNX net.
The HD67803 is a CAN / KNX Converter and it allows you to connect some CAN devices with a KNX net (for example light switches, actuators...).
The HD67804 is a CANopen / KNX Converter and it allows you to connect some CANopen devices with a KNX net (for example light switches, actuators...).
These converters are very easy to configure and allows you to interface a CAN/CANopen system with the KNX world.
On KNX side you can connect all the common KNX devices such as temperature sensors, shutters, light switches, actuators, alarms etc.
CAN / KNX series
HD67803-KNX-B2
CAN / KNX - Converter ( Ethernet Switch Inside for enter/exit connection, Housing type: B, Terminal Blocks Connectors )
| Ports | 1xKNX; 1xCAN | |
|---|---|---|
| KNX Protocol | KNX TP | |
| CAN Protocol | CAN | |
| Data Rates KNX | 9600 bit/s | |
| Data Rates CAN | Up to 1 Mbps | |
| KNX Connector | KNX Bus connector | |
| CAN Connector | 3way 5mm terminal block | |
| Power Supply | 8..24V AC; 12..35V DC | |
| Power Supply Connector | 2way 5mm terminal block | |
| Operating Temperature | -40° to +85° (-40°F to +185°F) | |
| Dimensions | 71x60x95 (DxWxH) | |
| Weight | 200g approx | |
| Mechanical Fixing | 35mm DIN Rail montage | |
| Software | SW67802 | |
HD67804-KNX-B2
CANopen / KNX - Converter ( Ethernet Switch Inside for enter/exit connection, Housing type: B, Terminal Blocks Connectors )
| Ports | 1xKNX; 1xCAN | |
|---|---|---|
| KNX Protocol | KNX TP | |
| CAN Protocol | CANopen | |
| Data Rates KNX | 9600 bit/s | |
| Data Rates CAN | Up to 1 Mbps | |
| KNX Connector | KNX Bus connector | |
| CAN Connector | 3way 5mm terminal block | |
| Power Supply | 8..24V AC; 12..35V DC | |
| Power Supply Connector | 2way 5mm terminal block | |
| Operating Temperature | -40° to +85° (-40°F to +185°F) | |
| Dimensions | 71x60x95 (DxWxH) | |
| Weight | 200g approx | |
| Mechanical Fixing | 35mm DIN Rail montage | |
| Software | SW67804 | |
Accessories
| Order Code | Description |
|---|---|
| AC34011 | Isolated Converter 100..240V AC to 12V DC stabilized - AC/DC |
| AC34012 | Isolated Converter 100..240V AC to 24V DC stabilized - AC/DC |
| AC34-AB1TP | KNX Power Supply - KNX out 640mA - in 240VAC |
| AC34-AG1TP | KNX Power Supply - KNX out 640mA + AUX out 30VDC - in 240VAC |
