SuperPro 6104NGP is designed with high programming speed in
mind. Our semiconductor manufacturer approved algorithms,
precision and clean signals guarantee high programming yield.
Special design was made to eliminate overshoot and ground bounce.
Algorithms are performed with state machine architecture constructed
with FPGA to achieve a ultra-high programming speed.

Largest Device Support

Located in Silicon Valley, we keep good relationships with many major
IC companies that are important for us to continuously support new
devices. SuperPro 6104NGP currently supports more than 99,800
devices, which is the largest device library in the programming industry.
Requested device algorithms can be added within a week - average
lead time from other manufacturers is over two months.

Project Files

The project file stores preparations before programming. Users could
also restore and save work environment. The project file includes
device type, buffer data, operation option settings, configuration bit
settings and batch commands. Project files may be password protected
to increase security and reliability when operated by untrained operators.

Auto Function

The Auto function organizes different functions into a sequential group
(erase, blank check, program, verify and protect). Functions are executed
in sequential order similar to a batch command.

Production Mode

Once a chip is inserted correctly, the programmer automatically starts batch
command of erase, blank check, program and verify. Auto chip detection saves
time and increases efficiency.

Production Statistics

A log file could be used to save operation information before exiting the
program. Log files can also be used to facilitate quality tracking.

Factory Mode

This mode is designed for factory volume production. To prevent operation
errors from destroying chips and wrong data written to the chip, SuperPro
will operate in the Auto function mode.The administrator can set a password
to prevent unauthorized access to the system.

Auto Recognition of File Types

We support almost all kinds of known file formats including file formats with
automatic recognition functions: Binary, Intel (linear & segmented) Hex,
Motorola S, Tektronix (linear & segmented), JEDEC, POF, etc.

Auto Increment of Serial Numbers

Auto-generation of electronic serial numbers is available on Superpro
6104NGP. This feature is implemented by setting Auto Increment in Operation
Option. Auto Increment allows users to add unique serial number into the
device. After each successful programming, the software automatically
changes the value by the specified increment mode.

Intellectual Property Protection

Password settings available in both PC and stand-alone mode.
