owa450

Part No.: MPOW-owa450
The Perfect Platform for controlling and monitoring your industrial Machines and Vehicles

產品介紹

Ideal for Construction equipment, Cargo and Material handling, agriculture and forestry machinery, fleet management, mining and minerals, electrical vehicles, preventive maintenance and any digital transformation and Industry 4.0 projects demanding Edge computing capabilities.


Description

The owa450 is the needed platform for you to collect data in the easiest possible way, getting your company the complete control of the application. The owa450 is the perfect solution for controlling and monitoring your industrial machines and vehicles, with its powerful Cortex A8 microprocessor (800MHz) can process the information at the Edge and your application will decide the meaningful information to be sent to the Cloud.


Processor ARM Cortex A8 32 bit 800MHz
Memory 512MB DDR3; 1GB NAND Flash
GSM Communication Global LTE Cat 1
Interfaces Up to 4 CAN Bus; Wifi&BT 4.2; Audio Codec, etc...
Enclosure IP40 (protection against dust)

Technical Specification

CPU
  • ARM Cortex A8 at 800MHz clock speed.
  • Linux Kernel 4.19.94
  • Debian 10 File System
  • NAND FLASH 1GB (Up to 2 GB)
  • DDR3 512MB (Up to 1 GB)
  • MicroSD card holder for additional storage.
GNSS
  • Receiver: GPS/GLONASS/GALILEO/QZSS/BeiDou.
  • 72-channel continuous tracking receiver.
  • SBAS: WAAS, EGNOS, MSAS, GAGAN.
  • Update Rate: up to 10Hz.
  • Accuracy: 2 meters CEP.
  • Signal Acquisition:
    • Cold Start: 26 s.
    • Hot Start: < 1.5 s.
  • Signal Reacquisition: < 1 s.
  • Active Antenna Power Supply: +3.3V
* Features availability depending on version.
Interfaces
  • Up to 4 CAN bus
    • 2 CAN bus supporting full speed 1Mbps CAN 2.0B.
    • 2 CAN FD supporting 8Mbps
  • Up to 2 K-line bus.
  • Integrated sensors.
    • Programmable 9 axis sensor, accelerometer, gyroscope and magnetometer.
  • TPM 2.0
  • 10 configurable digital input/outputs:
    • 50V max inputs (logic low <1.5V, high >3V).
    • All inputs function as wake signals for low power modes.
    • All inputs can be used as counters (odometer). 32bit, 3Khz max.
    • 8 open collector outputs (200mA each).
    • 2 high-side switches to Vin for output (1A each)
    • Short-circuit protection for all outputs
  • Optional 3 extra digital inputs in expansion connector
  • 4 analog inputs:
    • 12 bit resolution, 1% accuracy.
    • Multiplexed with digital I/O pins.
    • 0-5.12V (5mV per bit) or 0-30.72V (30mV per bit) configurable by SW
  • Maxim 1-Wire.
  • MicroSD card holder
  • USB Host 2.0
  • 3 external RS232 ports. 6 pins configurable by SW as follows:
    • 3 x (TX/RX) or
    • 1 x (TX/RX) & 1 x (TX/RX/CTS/RTS)
  • Up to two RS485 port.
  • Ethernet 10/100Base-TX
  • Vout 5V power output (500mA max).
  • FAKRA antenna connectors
  • 4 LEDs for status indication
  • Audio CODEC for external microphone and speaker
* Availability of features depends on models
Power Supply
  • Nominal range of 9V to 48V.
  • Typical consumption at 24 V
Off 0.335 mA
Standby 9.88 mA
RUN 47 mA
Run + GSM + GPS 73 mA
Batteries
  • Back-up when there is no power supply available:
    • Standard backup battery for RTC. Duration 10 years.
    • Optional rechargeable Battery Li-Ion 3.7V. Inserted via rear battery cover.
Safety Operating
Temperature Range
without Li-ion Battery		 -40 °C to +75 °C
Safety Purposes
Operating Temperature Range
with Li-ion Battery
-40 °C to +55 °C (from external power supply)
-20 °C to +55 °C (battery can power the unit)
0 °C to +45 °C (battery will be charged if external power available)

* Industrial temperature range components -40 °C to 85 °C
LTE Cat 1 with UMTS/HSPA and GSM fallback
  • DL 10.2Mbps, UL 5.2Mbps
  • GPRS Class B, Class 12 (4&4).
  • No standard voice calls support, calls must be done using a SIP client.
owa450(P):
  • LTE Cat 1 bands:1, 2, 3, 4, 5, 7, 8, 12, 13, 18, 19, 20, 26, 28, 66
  • UMTS/HSPA+ bands: 1, 2, 3, 4, 5, 6, 8, 19
  • GSM/GPRS/EDGE: Quad band
Enclosure
  • Environmental protection to IP40 standard. (protection against dust).
  • Dimension: L=150 x W=94 x H=32 mm)
  • Weight: 254g
  • Material: PC+ABS.
  • System connectors: Molex Microfit 24 way 43045-2400
  • MicroSIM
  • MicroSD
  • Ethernet RJ45 or M12
Development Kit Includes: Developer’s board owa450, power supply cables, cables for interfaces, speaker, microphone, antennas, web access to: cross compiler, API, libraries, manuals and application notes.
