Features

• FDDI FT-232R USB chp
• Plug & Play installation
• 3000V DC isolation protection
• Built in 15KV ESD protection for signals
• RS-422/485 surge & over current protection
• Built in 100 ohm Termination resistor
• Windows, MAC OS, Linux driver support

Specifications

Serial Interface

• Port number: 1
• Port Type: RS-232 x 1 Port ( DB9 ) or RS-422/485 x 1 Port (4-pin Terminal Block, Auto Select)
• Connector: Male DB9 / 4-pin Terminal Block
• RS-232 Speed: 300 bps ~ 921.6 Kbps
• 422/485 Speed: 300 bps ~ 230.4 Kbps
• Parity: None, Odd, Even, Mark, Space
• Data Bit: 7, 8
• Stop Bit: 1, 2
• RS-232: Rx, Tx, GND, RTS, CTS, DTR, DSR,
• RS-422: Rx+, Rx-, Tx+, Tx-
• RS-485: Data+, Data-
• Built–in: RS-422/485 pull high / low Resistor
• Protection: 422/485 Surge & Over Current Protection Built in 15KV ESD protection for all signals
• Isolation: 3000V DC Optical isolation protection
• Termination: Built in 100 Ohm Termination resistor
• Resistor: switch On/Off
• Distance: Up to 1250m

Driver Support

• Windows: 98SE/ 2000/ XP/ 2003/ Server/ VISTA/ WIN 7/ WIN 8 / XP Embedded/ WinCE 4.2/ 5.0/ 6.0
• MAC: OS OSX/ OS9
• Linux: 2.4/ 2.6

USB Interface

• Chipset: FDDI FT-232R
• USB spec: USB 1.0, 1.1, 2.0
• Connector: USB Type B
• Baud Rates: Full speed 12Mbps

Environment

• Temperature:
  • Operating: 0°C ~ 65°C (32°F ~ 149°F)
  • Storage: -20°C ~ 70°C (-4°F ~ 158°F)
• Humidity:
  • Operating: 10% ~ 95% non-condensing
  • Storage: 5% ~ 95% non-condensing

Power

• Input: USB Bus power, DC5V, 50mA

Dimension & Weight

• Dimension: 85 x 80 x 28 mm
• Weight: 90g

LED

• SYS (PWR), Rx, Tx

Regulatory Approval

• FCC: Part15 Class A
• CE: EN55022 Class A, EN55024
• RoHS: Compliance

Warranty

• 1 Year
