Features

• Linux OS, S/W Programmable
• API/CGI for AP layer Application
• Multiple Serial Interfaces
• Powerful Computing capability
• On board 16 x GPIO
• Web Browser configuration
• Easy installation Windows utility
• On line F/W upgrade

Specifications

Hardware

• CPU: ARM Cortex A53 CPU, 1.2 GHz
• RAM: 1 GBytes SDRAM
• ROM: 8G Bytes Flash ROM (Micro SD card)
• OS: Linux OS, API & CGI available
• Watchdog: Built in H/W Watchdog timer
• RTC: Built in RTC

Ethernet

• Port number: 1
• Port Type: RJ-45 Connector
• Speed: 10 / 100 Mbps ( Auto Detect )
• Protocol: ARP, IP, ICMP, UDP, TCP, HTTP, DHCP, PPPoE, DDNS, NTP, FTP, TELNET
• Mode: TCP Server/ TCP Client/ UDP
• Setup: HTTP Browser Setup (IE, Chrome, Firefox),
• Security: Login Password
• Protection: Built-in 1.5KV Magnetic Isolation

Serial Interface

• Port number: 4
• Port Type: RS-232 x 1 Port ( DB9, Full ), UART x 1 Port ( DB9, Tx, Rx, GND, PW) RS-422/485 x 2 Port (Software select)
• Connector: Male DB9 x 2 / 4-pin Terminal Block x 2
• Speed: 300 bps ~ 230.4 Kbps
• Parity: None, Odd, Even, Mark, Space
• Data Bit: 5, 6, 7, 8
• Stop Bit: 1, 2
• Protection: 422/485 Surge & Over Current Protection Built in 15KV ESD protection for all signals

Storage Interface

• Micro SD slot: Micro SD card (for OS)

Display Interface

• Port number: HDMI x 1  for Video & Audio output

USB Interface

• Port number: 2
• Function: Storage, WiFi Dongle, Bluetooth Dongle

Software Features

• OS Supported: Windows 2000/2003/XP/Vista/Win 7/Win 8
• Configuration: Window Utility, Web Browser

Digital I/O

• GPIO x 16 pin

LED

• PWR, SYS, Tx/Rx0, Tx/Rx1, Tx/Rx2, Tx/Rx3

Power

• Input: DC 12 ~ 24V, 1000mA@ 12VDC

Environment

• Temperature:
  • Operating: 0°C ~ 65°C (32°F ~ 149°F)
  • Storage: -10°C ~ 70°C (-14°F ~ 158°F)
• Humidity:
  • Operating: 10% ~ 95% non-condensing
  • Storage: 5% ~ 95% non-condensing

Regulatory Approval

• FCC: Part15 Class A
• CE: EN55022 Class A, EN55024
• RoHS: Compliance

Warranty

• 1 Year
